JICP Chisel Head Type Nozzle

420 heat treatment, the drill tip deeply penetrates the blockage andwateelosbckig material and wash it to the rear.
Usefortotalblockage.
Applicable:150－600mm
Max Pressure:4000Psi/275Bar

获取报价 +

上一篇：JIG Grenade Type Nozzle
下一篇：JRC Combination Jet Fast Rotating Nozzle

规格参数
资料下载

规格参数

MODEL	Inlet	Front Jet	Rear Jet	Insert	Size	Weight
JICP45-3/8	3/8" F	1x0°+3x15°	5x20°	Orifice 20	25x40	70g
JICP45-1/2	1/2" F	1x0°+3x15°	5x20°	M6	41x65	0.34kg
JICP46-3/4	3/4" F	1x0°+3x15°	6x20°	M6	52x85	0.73kg
JIC4P6-1	1" F	1x0°+3x15°	6x20°	M6	65x110	1.44kg
