ST SERIES 3200PSI/3700PSI Gas Engine Pressure Water Jetter

ST Series 15HP/420cc gas engine, hose reel on-board and four wheel frame, COMMERCIAL direct drive triplex pump

Commercial grade brass forged triplex pump, pressure adjustable, built with easy start valve and pulse valve. Performance proven gas engine, EU5 or EPA certified. Engine and pump mount with anti-vibration rubber feet. Powder coating four wheel frame, bolt on handle, built with hose on board fixture. Removable hose reel with short connection hose. 10" solid wheel with plastic hub without bearing.

Standard Accessories:

ID1/4 (6.4mm) x 200FT(60m) pressure jetting hose, 1/4" M

Standard drilled fast penetrating nozzle, normal cleaning nozzle, and inwall cleaning fast rotating nozzle, and more nozzle optional 12V-20A/H battery, foot actuated valve, pressure washing gunand nozzle for option.

获取报价 +

上一篇：BS SERIES 1500PSI Eectric Motor Pressure Water Jetter
下一篇：SH SERIES 2000PSI-13.7GPM Electric Motor Pressure Water Jetter

规格参数
应用领域
资料下载

规格参数

MODEL：DCC-22/25ST

Max Pressure	3200Psi / 220Bar
Rated Flow	6.6Gpm / 25Lpm
Pump Model	DBC-1514A, Brass
Power And Type	15hp/420cc, OHV
Shipping Size	80x53x64cm
Shipping Weight	80kgs

MODEL：DCC-26/21ST

Max Pressure	3700Psi / 260Bar
Rated Flow	5.7Gpm / 22Lpm
Pump Model	DBQ-20146G4, Gear reduction
Power And Type	15hp/420cc, OHV
Shipping Size	80x53x64cm
Shipping Weight	80kgs
